Product Introduction
CTX250-5-52-R
- Part Number
- CTX250-5-52-R
- Manufacturer/Brand
- Eaton - Electronics Division
- Description
- FIXED IND 250UH 9.2A 40 MOHM TH
- Category
- Fixed Inductors
- RoHs Status
- Lead free / RoHS Compliant
- Series
- CTX
- Quantity
- 298pcs Stock Available.
Images are for reference only
See Product Specifications
See Product Specifications
Product Specifications
| Part Number | CTX250-5-52-R |
| Datasheet | CTX250-5-52-R datasheet |
| Description | FIXED IND 250UH 9.2A 40 MOHM TH |
| Manufacturer | Eaton - Electronics Division |
| Series | CTX |
| Part Status | Active |
| Type | Toroidal |
| Material - Core | Iron Powder |
| Inductance | 250µH |
| Tolerance | ±20% |
| Current Rating | 9.2A |
| Current - Saturation | 8.1A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 40 mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 75°C |
| Inductance Frequency - Test | 100kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Supplier Device Package | - |
| Size / Dimension | 2.114" Dia x 0.957" W (53.70mm x 24.30mm) |
| Height - Seated (Max) | - |
