Home / Products / Capacitors / Aluminum Electrolytic Capacitors / AHA107M35G24B-F
Product Introduction
AHA107M35G24B-F
- Part Number
- AHA107M35G24B-F
- Manufacturer/Brand
- Cornell Dubilier Electronics (CDE)
- Description
- CAP ALUM 100UF 20 35V SMD
- Category
- Aluminum Electrolytic Capacitors
- RoHs Status
- Lead free / RoHS Compliant
- Series
- AHA
- Quantity
- 3834pcs Stock Available.
Images are for reference only
See Product Specifications
See Product Specifications
Product Specifications
| Part Number | AHA107M35G24B-F |
| Datasheet | AHA107M35G24B-F datasheet |
| Description | CAP ALUM 100UF 20 35V SMD |
| Manufacturer | Cornell Dubilier Electronics (CDE) |
| Series | AHA |
| Part Status | Discontinued at Digi-Key |
| Capacitance | 100µF |
| Tolerance | ±20% |
| Voltage - Rated | 35V |
| ESR (Equivalent Series Resistance) | 2.3 Ohm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive, Bypass, Decoupling |
| Ripple Current @ Low Frequency | 160mA @ 120Hz |
| Ripple Current @ High Frequency | 272mA @ 10kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.402" (10.20mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
