Product Introduction
S4924-563K
- Part Number
- S4924-563K
- Manufacturer/Brand
- API Delevan Inc.
- Description
- FIXED IND 56UH 369MA 2.23 OHM
- Category
- Fixed Inductors
- RoHs Status
- Lead free / RoHS Compliant
- Series
- S4924
- Quantity
- 33pcs Stock Available.
Images are for reference only
See Product Specifications
See Product Specifications
Product Specifications
| Part Number | S4924-563K |
| Datasheet | S4924-563K datasheet |
| Description | FIXED IND 56UH 369MA 2.23 OHM |
| Manufacturer | API Delevan Inc. |
| Series | S4924 |
| Part Status | Active |
| Type | - |
| Material - Core | Ferrite |
| Inductance | 56µH |
| Tolerance | ±10% |
| Current Rating | 369mA |
| Current - Saturation | 124mA |
| Shielding | Shielded |
| DC Resistance (DCR) | 2.23 Ohm Max |
| Q @ Freq | 50 @ 2.5MHz |
| Frequency - Self Resonant | 25MHz |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 2.5MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.505" L x 0.240" W (12.82mm x 6.09mm) |
| Height - Seated (Max) | 0.220" (5.58mm) |
