Product Introduction

MECF-05-01-L-DV

Part Number
MECF-05-01-L-DV
Manufacturer/Brand
Samtec Inc.
Description
CONN EDGE DUAL FMALE 10POS 0.05
Category
Card Edge Connectors - Edgeboard Connectors
RoHs Status
Lead free / RoHS Compliant
Series
MECF
Quantity
188pcs Stock Available.

Quick Order

Company
Contact
Phone
Email
Country
Content
Images are for reference only
See Product Specifications

Product Specifications

Part Number MECF-05-01-L-DV
Datasheet MECF-05-01-L-DV datasheet
Description CONN EDGE DUAL FMALE 10POS 0.05
Manufacturer Samtec Inc.
Series MECF
Part Status Active
Card Type Non Specified - Dual Edge
Gender Female
Number of Positions/Bay/Row 5
Number of Positions 10
Card Thickness 0.093" (2.36mm)
Number of Rows 2
Pitch 0.050" (1.27mm)
Read Out Dual
Features Board Guide
Mounting Type Surface Mount
Termination Solder
Contact Material Beryllium Copper
Contact Finish Gold
Contact Finish Thickness 10.0µin (0.25µm)
Contact Type Cantilever
Color Black
Flange Feature -
Operating Temperature -55°C ~ 125°C
