Product Introduction
4922R-471L
- Part Number
- 4922R-471L
- Manufacturer/Brand
- API Delevan Inc.
- Description
- FIXED IND 470NH 6A 10 MOHM SMD
- Category
- Fixed Inductors
- RoHs Status
- Lead free / RoHS Compliant
- Series
- 4922R
- Quantity
- 33pcs Stock Available.
Images are for reference only
See Product Specifications
See Product Specifications
Product Specifications
| Part Number | 4922R-471L |
| Datasheet | 4922R-471L datasheet |
| Description | FIXED IND 470NH 6A 10 MOHM SMD |
| Manufacturer | API Delevan Inc. |
| Series | 4922R |
| Part Status | Active |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 470nH |
| Tolerance | ±15% |
| Current Rating | 6A |
| Current - Saturation | 6A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 10 mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 1kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.505" L x 0.240" W (12.82mm x 6.09mm) |
| Height - Seated (Max) | 0.230" (5.84mm) |
