Home / Products / Capacitors / Aluminum Electrolytic Capacitors / EET-UQ2W391KA
Product Introduction
EET-UQ2W391KA
- Part Number
- EET-UQ2W391KA
- Manufacturer/Brand
- Panasonic Electronic Components
- Description
- CAP ALUM 390UF 20 450V SNAP
- Category
- Aluminum Electrolytic Capacitors
- RoHs Status
- Lead free / RoHS Compliant
- Series
- TS-UQ
- Quantity
- 1639pcs Stock Available.
Images are for reference only
See Product Specifications
See Product Specifications
Product Specifications
| Part Number | EET-UQ2W391KA |
| Datasheet | EET-UQ2W391KA datasheet |
| Description | CAP ALUM 390UF 20 450V SNAP |
| Manufacturer | Panasonic Electronic Components |
| Series | TS-UQ |
| Part Status | Obsolete |
| Capacitance | 390µF |
| Tolerance | ±20% |
| Voltage - Rated | 450V |
| ESR (Equivalent Series Resistance) | 510 mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.24A @ 120Hz |
| Ripple Current @ High Frequency | 3.136A @ 10kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.575" (40.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
