Product Introduction
RCG080522R0JNEA
- Part Number
- RCG080522R0JNEA
- Manufacturer/Brand
- Vishay Dale
- Description
- RES SMD 22 OHM 5 1/8W 0805
- Category
- Chip Resistor - Surface Mount
- RoHs Status
- Lead free / RoHS Compliant
- Series
- RCG
- Quantity
- 8545pcs Stock Available.
Images are for reference only
See Product Specifications
See Product Specifications
Product Specifications
| Part Number | RCG080522R0JNEA |
| Datasheet | RCG080522R0JNEA datasheet |
| Description | RES SMD 22 OHM 5 1/8W 0805 |
| Manufacturer | Vishay Dale |
| Series | RCG |
| Part Status | Active |
| Resistance | 22 Ohms |
| Tolerance | ±5% |
| Power (Watts) | 0.125W, 1/8W |
| Composition | Thick Film |
| Features | - |
| Temperature Coefficient | ±200ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Package / Case | 0805 (2012 Metric) |
| Supplier Device Package | 0805 |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Height - Seated (Max) | 0.020" (0.50mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
