Home / Products / Capacitors / Aluminum Electrolytic Capacitors / LNT1A333MSE
Product Introduction
LNT1A333MSE
- Part Number
- LNT1A333MSE
- Manufacturer/Brand
- Nichicon
- Description
- CAP ALUM 33000UF 20 10V SCREW
- Category
- Aluminum Electrolytic Capacitors
- RoHs Status
- Lead free / RoHS Compliant
- Series
- LNT
- Quantity
- 168pcs Stock Available.
Images are for reference only
See Product Specifications
See Product Specifications
Product Specifications
| Part Number | LNT1A333MSE |
| Datasheet | LNT1A333MSE datasheet |
| Description | CAP ALUM 33000UF 20 10V SCREW |
| Manufacturer | Nichicon |
| Series | LNT |
| Part Status | Active |
| Capacitance | 33000µF |
| Tolerance | ±20% |
| Voltage - Rated | 10V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 4.8A @ 120Hz |
| Ripple Current @ High Frequency | 5.52A @ 10kHz |
| Impedance | - |
| Lead Spacing | 0.500" (12.70mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 3.268" (83.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
