Product Introduction
TNPW0603249RBEEA
- Part Number
- TNPW0603249RBEEA
- Manufacturer/Brand
- Vishay Dale
- Description
- RES 249 OHM 0.1 1/8W 0603
- Category
- Chip Resistor - Surface Mount
- RoHs Status
- Lead free / RoHS Compliant
- Series
- TNPW e3
- Quantity
- 20111pcs Stock Available.
Images are for reference only
See Product Specifications
See Product Specifications
Product Specifications
| Part Number | TNPW0603249RBEEA |
| Datasheet | TNPW0603249RBEEA datasheet |
| Description | RES 249 OHM 0.1 1/8W 0603 |
| Manufacturer | Vishay Dale |
| Series | TNPW e3 |
| Part Status | Active |
| Resistance | 249 Ohms |
| Tolerance | ±0.1% |
| Power (Watts) | 0.125W, 1/8W |
| Composition | Thin Film |
| Features | Anti-Sulfur, Automotive AEC-Q200, Moisture Resistant |
| Temperature Coefficient | ±25ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Package / Case | 0603 (1608 Metric) |
| Supplier Device Package | 0603 |
| Size / Dimension | 0.063" L x 0.033" W (1.60mm x 0.85mm) |
| Height - Seated (Max) | 0.022" (0.55mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
